Recirculation / Neutralization System, 200 gal, Auto pH Monitoring

The BHS Recirculation / Neutralization System (RNS) controls, filters, and recirculates water used for cleaning industrial batteries. The RNS comes standard with a spray wand, 10’ (3 m) hose, and a 12 V dc sump pump with float switch.The BHS Battery Wash Cabinet, coupled with the RNS, creates a closed loop system that contains and controls the water used for cleaning industrial batteries.Voltages available in 120 1ph 60Hz only.Features & Benefits:Filters down to 5 micronsEasy filter replacementRotary gear pump features stainless steel internal parts for extended component lifeRemovable front panels for convenient maintenanceClosed loop system (when coupled with a BWC) eliminates water supply and floor drains70 psi (2.4 bar) at 12 gal/min (45 L/min) for high-flood battery wash-downIn-line pH monitoring system aids in keeping proper pH levelFewest number of components in the industry lowers operating costsWorks with manual or automatic BHS Battery Wash CabinetsOn-demand, automatic start system100-micron bag filter insert captures larger particlesAuto shut-off for pH out of safe operating rangeAuto shut-off and indicator light for filter serviceAuto shut-off for low water levelAdjustable timed recirculation mode for pH adjustingBuilt-in ozone purification systemFrame ConstructionStainless SteelWater Pump Capacity12 gal/min @ 70 psi / 45 L/min @ 3.8 – 4.8 barWater Pump Motor1.5 hp / 1.12 kWSump Pump Capacity24 gal/min / 91 L/minReservoir Capacity200 gal / 757 LFilter Capacity5 micron Main / 100 micron ReturnpH Metering TypeAutomatic – Inline SystemRequired Voltage120 V / 1 ph / 60 HzOverall Length48” / 1219 mmOverall Width42.4” / 1077 mmOverall Height48.6” / 1234 mmCapacity200 gallon / 757 L Integral Tank
